| Temperature range | -70ºC~+100ºC(150ºC)(A:+25ºC B:0ºC C:-20ºC D:-40ºC E:-50ºC F:-60ºC G:-70ºC) |
| Humidity range | 20%-98%R.H. (10%-98%R.H/5%-98%R.H are special selection conditions) |
| Temperature and humidity resolution accuracy/uniformity | ±0.1°CC;±0.1%R.H./±1.0°C: ±3.0%R.H. |
| Temperature and humidity control accuracy / fluctuation | ±1.0°C; ±2.0%R.H./±0.5°C; ±2.0%R.H. |
| Temperature Rising/Falling Time | approx. 4.0°C/min; approx. 1.0°C/min (5-10°C drop per minute for special selection conditions) |
| Material of internal and external parts | Exterior: Premium cold plate nano-baked lacquer
Interior: stainless steel |
| Insulation material | High temperature resistant high density ethylene chloride-based vinyl acetate foam insulator material |
| Cooling system | Air-cooled/single stage compressor (-20°C),air and water-cooled/double stage compressor (-40°C-70°C) |
| Protection devices | Fuseless switch, compressor overload protection switch, refrigerant high and low pressure protection switch, over humidity and over temperature protection switch, fuse, fault warning system |
| Accessories | Viewing window, 50 mm test hole, PL box interior light, divider, wet and dry ball gauze |
| Controllers | TEMI, TH-900C (South Korean) /OYO (Japan) |
| Compressors | Tecumseh |
| Power supply | 1Φ220VAC±10% 50/60Hz &3Φ380VAC±10%50/60Hz |
FAQ:
1. Do you offer after-sales service? How can I ask for that? And how about the warranty?
A:Every machine from our factory has a 14-month warranty after shipment. Generally, we offer 12 months for the FREE maintenance, while
considering of sea transportation, we can extend 2 months for our customers.
If your machine doesn't work, you can send E-mail to us and we will try our best to find the problem by email or video chat if neccesary.
After confirmation of the problem, we can send you new spare parts or provide on-site repair.
2. What's the delivery term?
A:At most of time, we have stock in the factory. If there is no stock, normally, the delivery time is 15-20 working days after deposit receipt. If you are in urgent need, we can consider making a special arrangement for you.
3. Do you accept customization service? Can I have my logo on the machine?
A:Yes, of course. We can not only offer standard machines, but also customized machines according to your requirements. And we can also put
your logo on the machine.
4. How to install and use the product?
A:We will send you operating instructions, English video by Email. Or you can download on our officail website directly.Most of our machine is
shipped with a whole part, which means it is already installed, all you need to do is to connect the power cable and start to
use. And if possible, we can also install your machine at site.
